Use high-quality hydraulic pump station, strong power, large-capacity battery, and lasting power.
The "C"-shaped steel door frame manufactured by special rolling process is firm and safe.
The design structure of the oil barrel truck is simple and lightweight, and the operation is simple and labor-saving.
High-quality oil cylinder, fast lifting speed, lifting height can reach 450mm.
It can be equipped with electronic weighing scale, with functions of zero setting, tare, weighing, etc., with an accuracy of 3/1000.
The advantage of the oil drum truck is that the structure of the whole vehicle is simple and light, and the operation is simple and labor-saving. One person can complete the transportation, stacking, stacking and loading and unloading of the entire oil drum.
| Model No. | TS0516 / TS0525 | |
|---|---|---|
| Operate method | Electric lifting, manpower walking | |
| Capacity | kg | 500 |
| Max.lifting height | mm | 1600/2500 |
| Lifting method | Electro-hydraulic lifting | |
| Precision(weighing scale) | g | 3/1000 |
| Overall length | mm | 1470 |
| Overall width | mm | 950/1100 |
| Overall height | mm | 2100 |
| Net weight | kg | 210 |
| Lifting motor | v/kw | 1.6 |
| Battery | v/Ah | 12/120 |
| Charger | v/A | 12V15A |
| Rear wheel size | mm | Φ180*50 |
| Front wheel size | mm | Φ180*50 |
| Wheel material | Nylon | |
| Front support leg inner width | mm | 640 |
| Front support leg outer width | mm | 840 |
| Turning radius | mm | 1500 |
| Lifting speed | mm/s | 120 |
Meet EN1570 norm and ANSI/ASME safety standards (full electric type). Electric lifting, Electric walking. Anti shear clip design is adopted to prevent pinch injury. With overload protection, it is more reliable and safer. Electromagnetic braking is safer.
Safe drum dumping requires well-designed, ergonomic drum handling equipment to reduce risks of injury or property damage. Our hydraulic Drum Carriers, drum dumpers A308 combine incredible strength with simple drum handling by one person.
Heavy duty rough terrain lift table ideal for use outside, such as in Garden. Handle with tool box pneumatic tires with brake system. protects your goods, tepless rate of lowering system remains irrespective of the weight of the load.
